BOLT THREADING MACHINE

0 out of 5 based on 0 customer ratings

Bolt Threading Machine is used to cut the external threads with the help of Tangential chaser. Bolt Threading Chaser is used as a cutter in machine. Job remain still, Die-head rotates and different type of threads can be cut such as BSW, UNF, METRIC, UNC, ACME Threads.

Category: Threading Machines

Description
Reviews (0)

A Bolt Threading Machine is basically used for creating external threads on job and “chasing method” is used to execute this task to threading the bolts. HSS Bolt Threading Tangential Chasers are used as cutters. Job remains un-moved while the die head rotates creating super-fine threads. The Bolt Threading Machine is manufactured with us allows its users to create a wide range of threads like BSP, MATRIX, BSPT, NPT, UNF,UNC, BSW, Acme Threads but again the entire preference depends on the type of chasers. Generally this is made up these components mentioned below.

Base
Head Stock
Saddle
Bed or Pillar Type Clamping Vice
Die-Head.

Head stock: It is used to provide contented rigidity and enduring alignment with the carriage ways. This head stock is made up unadulterated and shaven alloy steel and shafts are made using heated alloy steel which increases in durability.

Pillar bed: This bed is designed to provide operative convenience to the user. This bed is smooth yet is a rigid construction. Chrome plated pillars are used to direct and shore up the carriage. Guards, attached to the carriages, avert damage to the ground surfaces of the ways.

Saddle: It is fitted very precisely on two pillars and runs on them very smoothly and accurately to the head stock alignment.

Apron: This gives momentum to the saddle with head transfer along with the pillars. This is done on steel rack and rigid arrangements. Gears are made up of supreme quality steel.

Vice jaws: The vice jaws made from the best quality alloy steel are fitted on the saddle well aligned with the head stock center fitted in a heavy duty box type vice. The jaws are heat treated. The movements of jaws are controlled by a screw on the saddle.

Range of IMC Bolt Threading Die Heads.

Diameter 1/4″ to 1″ do/-
Diameter 3/8″ to 1.1/2″ do/-
Diameter 1/2″ to 2.1/2″ do/-
Diameter 1″ to 4″ do/-
